E-Catalog > เครื่องมือวัด ทดสอบ และควบคุม > เครื่องทดสอบอเนกประสงค์ระบบเครื่องกลไฟฟ้า

          SUNS Strom Series Electromechanical Universal Testing Machine is capable of conducting mechanical tests such as tension, compression, bending, shearing, peeling, and tearing on a wide range of materials, including both metals and non-metals. These machines are widely utilized in fields such as aerospace, nuclear energy, defense, and higher education institutions. The Storm series provides an enhanced choice for users in R&D community.

Common Specifications: Position Measurement Accuracy: ±0.02 mm or 0.05% of displacement (whichever is greater). Crosshead Speed Accuracy (Zero or constant load): ±0.1% of set speed. Load Measurement Accuracy: ±0.5% of reading down to 0.4/100 of load cell capacity; Strain Measurement Accuracy: ±0.5% of reading down to 1/50 of full range with ASTM E83 class B or ISO 9513 class 0.5 extensometer. Operating Temperature: -10 °C to +38 °C (+14 °F to +100 °F); Storage Temperature: -40 °C to +66 °C (-40 °F to +150 °F); Humidity Range: +10% to +90%, non[1]condensing. Atmosphere: Designed for use under normal laboratory conditions. Protective measures may be required if excessive dust, corrosive fumes, electromagnetic Þeld or hazardous conditions are encountered.

 Notes:

1. All systems force measurement meets or surpasses the following standards: ASTM E 4, BS 1610, DIN 51221, ISO 7500-1, EN10002-2 . SUNS recommends the systems are veriÞed on site at the time of installation as required by ASTM E 4 and ISO 7500-1 standards.

 2. Strain measurement system meets or surpasses the following standards: ASTM E 83, BS 3846, ISO 9513, EN 10002-4.

3. Contact us for details of Extra high or wide load frames and extra high or low speed drive systems.

4. All systems conform to all relevant European standards and carry a CE mark.

5. Tension space is for total vertical test distance, excludes the height of grips,Þxtures, load cells, connectors.

6. All of the speciÞcations shown above are subject to change without notice

*If you are interested in the product or have any questions, you can contact us at the address below.*

TCC ADVANCE TECH (THAILAND) CO., LTD.

104/ 107 Moo 12, Soi Rattanachock 12,Tanasit Road, T.Bangpra,A.Bangplee Samutprakan 10540.Thailand.

Tel : (66) 0-2174-6034~5 (อัตโนมัติ).

Mobile : 097-117-8657 (Sale 1)

Mobile : 086-355-7856 (Sale 2)

E-Mail : tcc.sale3@gmail.com
